Emotional moments in the electric vehicle interior
We are your expert for ev interior sound
KENDRION offers customer-specific solutions for the electric vehicle (ev) interior. For this purpose we supply structure-borne sound actuators with or without control unit.
The electrodynamic drive of the sound actuator transforms the body structure or the windshield into a sound converter in order to enhance the sound of smaller engines in the vehicle interior and thus increase the driving pleasure.
The ev car sound actuator offers a compact solution for both interior sound reinforcement and the smallest possible installation space. The KENDRION ev sound actuator not only enhances the conventional engine sound but also provides a completely new, unmistakable sound for hybrid and electric vehicles.
Benefits at a glance
- Lightweight: 75% lighter than a comparable speaker
- Small size: 80 % saving of installation space
- Excellent acoustics and natural sound
- High protection class IP6K9K
- Patented design
- Any mounting position
- Shockproof construction
- Noise source difficult to locate
- Can be used in passenger cars, trucks, buses, aircraft
|Function||structure-borne sound actuator for sound excitation of various mounting surfaces, e.g. windscreen|
|System||Structure-borne noise actuator Control unit: complex sound algorithm, audio amplifier & software|
|Frequency range||50 to 8,000 Hz|
|Dimensions||D60 mm x H40 mm|
|Temperature range||-40 °C to 80 °C|
|Sound pressure||max. 95 dB(A) at 1m distance|
|Further special features||Acoustic feedback of driving status; extended frequency range and long service life; more natural sound image due to the bending wave principle and thus low locatability; also suitable for exterior sound: meets AVAS requirements|
Further Sound Solutions
for exterior sound
KENDRION has developed a complete, ready-to-use AVAS solution, the PHANTONE platform, which can be easily installed in electric and hybrid vehicles.
