Modular I/O
Modular I/O terminal with EtherCAT fieldbus connection
The Kuhnke FIO is a modular I/O terminal with EtherCAT fieldbus connection. The FIO I/O terminal consists of a Bus Coupler or a controller and various I/O modules for connecting the process signals. The EtherCAT protocol is maintained up to the last module. If required, safety technology can be integrated in the form of safety I/O modules. All decentralized EtherCAT Bus Terminals are modularly expandable and are suitable for connecting sensors and actuators in control cabinets.
- EtherCAT down to the last terminal
- Perfect module variety
- Included Safety
Products
(58)
|
Title
|
Type
|
Function
|
Dimensions (W x H x D)
|
Product status
|
Mounting
|
Certifications
|
IP-Protection Class
|
Model
|
Integrated function
|
Field bus interfaces
|
Status indication
|
Housing material
|
Supply voltage
|
Operating temperature
|
Immunity
|
Digital I/Os (integrated)
|
Analogue I/Os (integrated)
|
Interfaces
|
identification-number
|
Details | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Kuhnke FIO DI16 1ms 2-wire GI |
694 451 44 | Digital IN 2-wire | 25 x 120 x 90 mm | Standard product | - | CE, UL | IP 20 | Control cabinet modul | - | EtherCAT | LEDs allocated to the point of termination | Aluminium frame, plastic housing | 24 V DC (-15% ... +20%) | 0 ... +55°C | Zone B according to EN 61131-2 | Inputs: 16DI channel-wise electrically isolated 500 V 1ms | - | - | - | |
|
Kuhnke FIO DO8 Relay NO 24V |
694 452 03 | Digital OUT Relais | 25 x 120 x 90 mm | Discontinued product | - | CE, UL | IP 20 | Control cabinet modul | - | EtherCAT | LEDs allocated to the point of termination | Aluminium frame, plastic housing | 24 V DC (-15% ... +20%) | 0 ... +55°C | Zone B according to EN 61131-2 | outputs: 8 relay outputs, NO, 2A | - | - | - | |
|
|
Kuhnke FIO DO8 Relay NO 230 VAC |
694 452 04 | Digital OUT Relais | 25 x 120 x 90 mm | Discontinued product | - | CE, UL | IP 20 | Control cabinet modul | - | EtherCAT | LEDs allocated to the point of termination | Aluminium frame, plastic housing | 24 V DC (-15% ... +20%) | 0 ... +55°C | Zone B according to EN 61131-2 | outputs: 8 relay outputs, NO, 2A | - | - | - | |
|
|
Kuhnke FIO AI4-I 12Bit |
694 441 01 | analogue | 25 x 120 x 90 mm | New Product: Kuhnke FIO AI4-I 12Bit CoE | - | CE, UL | IP 20 | Control cabinet modul | - | EtherCAT | LEDs allocated to the point of termination | Aluminium frame, plastic housing | 24 V DC (-15% ... +20%) | 0 ... +55°C | Zone B according to EN 61131-2 | - | inputs: 4 AI 0..20mA, 4..20mA 12Bit | - | - | |
|
|
Kuhnke FIO AI4-8-U 13Bit |
694 441 02 | analogue | 25 x 120 x 90 mm | New Product: Kuhnke FIO AI4-8-U 13Bit CoE | - | CE, UL | IP 20 | Control cabinet modul | - | EtherCAT | LEDs allocated to the point of termination | Aluminium frame, plastic housing | 24 V DC (-15% ... +20%) | 0 ... +55°C | Zone B according to EN 61131-2 | - | inputs: 4(DIFF.) or 8(SE) AI 0-10V, +/-10V 13Bit | - | - | |
|
|
Kuhnke FIO AI8-16-U 13Bit |
694 441 03 | analogue | 25 x 120 x 90 mm | New Product: Kuhnke FIO AI8-16-U 13Bit CoE | - | CE, UL | IP 20 | Control cabinet modul | - | EtherCAT | LEDs allocated to the point of termination | Aluminium frame, plastic housing | 24 V DC (-15% ... +20%) | 0 ... +55°C | Zone B according to EN 61131-2 | - | inputs: 8(DIFF.) or 16(SE) AI 0-10V, +/-10V 13Bit | - | - | |
|
|
Kuhnke FIO AI8-I 12Bit |
694 441 04 | analogue | 25 x 120 x 90 mm | New Product: Kuhnke FIO AI8-I 12Bit CoE | - | CE, UL | IP 20 | Control cabinet modul | - | EtherCAT | LEDs allocated to the point of termination | Aluminium frame, plastic housing | 24 V DC (-15% ... +20%) | 0 ... +55°C | Zone B according to EN 61131-2 | - | inputs: 8 AI 0..20mA, 4..20mA 12Bit | - | - | |
|
|
Kuhnke FIO AI4-I 12Bit CoE |
694 441 51 | analogue - easy configuration | 25 x 120 x 90 mm | Standard product | - | CE, UL | IP 20 | Control cabinet modul | - | EtherCAT | LEDs allocated to the point of termination | Aluminium frame, plastic housing | 24 V DC (-15% ... +20%) | 0 ... +55°C | Zone B according to EN 61131-2 | - | inputs: 4 AI 0..20mA, 4..20mA 12Bit | - | - | |
|
|
Kuhnke FIO AI4-8-U 13Bit CoE |
694 441 52 | analogue - easy configuration | 25 x 120 x 90 mm | Standard product | - | CE, UL | IP 20 | Control cabinet modul | - | EtherCAT | LEDs allocated to the point of termination | Aluminium frame, plastic housing | 24 V DC (-15% ... +20%) | 0 ... +55°C | Zone B according to EN 61131-2 | - | inputs: 4(DIFF.) or 8(SE) AI 0-10V, +/-10V 13Bit | - | - | |
|
|
Kuhnke FIO AI8-16-U 13Bit CoE |
694 441 53 | analogue - easy configuration | 25 x 120 x 90 mm | Standard product | - | CE, UL | IP 20 | Control cabinet modul | - | EtherCAT | LEDs allocated to the point of termination | Aluminium frame, plastic housing | 24 V DC (-15% ... +20%) | 0 ... +55°C | Zone B according to EN 61131-2 | - | inputs: 8(DIFF.) or 16(SE) AI 0-10V, +/-10V 13Bit | - | - | |
|
|
Kuhnke FIO AI8-I 12Bit CoE |
694 441 54 | analogue - easy configuration | 25 x 120 x 90 mm | Standard product | - | CE, UL | IP 20 | Control cabinet modul | - | EtherCAT | LEDs allocated to the point of termination | Aluminium frame, plastic housing | 24 V DC (-15% ... +20%) | 0 ... +55°C | Zone B according to EN 61131-2 | - | inputs: 8 AI 0..20mA, 4..20mA 12Bit | - | - | |
|
|
Kuhnke FIO AO4 12Bit |
694 442 02 | analogue | 25 x 120 x 90 mm | Standard product | - | CE, UL | IP 20 | Control cabinet modul | - | EtherCAT | LEDs allocated to the point of termination | Aluminium frame, plastic housing | 24 V DC (-15% ... +20%) | 0 ... +55°C | Zone B according to EN 61131-2 | - | outputs: 4 AO 0..10V, +/-10V, 0..20mA 12Bit | - | - | |
|
|
Kuhnke FIO AO4 16Bit CoE |
694 442 52 | analogue - easy configuration | 25 x 120 x 90 mm | Standard product | - | CE, UL | IP 20 | Control cabinet modul | - | EtherCAT | LEDs allocated to the point of termination | Aluminium frame, plastic housing | 24 V DC (-15% ... +20%) | 0 ... +55°C | Zone B according to EN 61131-2 | - | outputs: 4 AO 0..10V, +/-10V, 0(4)..20(24)mA 16Bit | - | - | |
|
|
Kuhnke FIO AI4-Thermo 16Bit |
694 443 05 | Temperature | 25 x 120 x 90 mm | New Product: Kuhnke FIO AI4-PT-NI-Thermo 16Bit CoE | - | CE, UL | IP 20 | Control cabinet modul | - | EtherCAT | LEDs allocated to the point of termination | Aluminium frame, plastic housing | 24 V DC (-15% ... +20%) | 0 ... +55°C | Zone B according to EN 61131-2 | - | inputs: 4 AI Thermocouple 16Bit | - | - | |
|
|
Kuhnke FIO AI4-PT-NI100 16Bit |
694 443 01 | Temperature | 25 x 120 x 90 mm | New Product: Kuhnke FIO AI4-PT-NI-Thermo 16Bit CoE | - | CE, UL | IP 20 | Control cabinet module | - | EtherCAT | LEDs allocated to the point of termination | Aluminium frame, plastic housing | 24 V DC (-15% ... +20%) | 0 ... +55°C | Zone B according to EN 61131-2 | - | inputs: 4 AI PT/NI100 16Bit | - | - | |
|
|
Kuhnke FIO AI8-PT-NI1000 16Bit |
694 443 04 | Temperature | 25 x 120 x 90 mm | New Product: Kuhnke FIO AI8-PT-NI-Thermo 16Bit CoE | - | CE, UL | IP 20 | Control cabinet modul | - | EtherCAT | LEDs allocated to the point of termination | Aluminium frame, plastic housing | 24 V DC (-15% ... +20%) | 0 ... +55°C | Zone B according to EN 61131-2 | - | inputs: 8 AI PT/NI1000 16Bit | - | - | |
|
|
Kuhnke FIO AI8-PT-NI100 16Bit |
694 443 02 | Temperature | 25 x 120 x 90 mm | New Product: Kuhnke FIO AI8-PT-NI-Thermo 16Bit CoE | - | CE, UL | IP 20 | Control cabinet modul | - | EtherCAT | LEDs allocated to the point of termination | Aluminium frame, plastic housing | 24 V DC (-15% ... +20%) | 0 ... +55°C | Zone B according to EN 61131-2 | - | inputs: 8 AI PT/NI100 16Bit | - | - | |
|
|
Kuhnke FIO AI4-PT-NI1000 16 Bit |
694 443 03 | Temperature | 25 x 120 x 90 mm | New Produkt: Kuhnke FIO AI4-PT-NI-Thermo 16Bit CoE | - | CE, UL | IP 20 | Control cabinet modul | - | EtherCAT | LED, der Klemmstelle | Aluminium frame, plastic housing | 24 V DC (-15% ... +20%) | 0 ... +55°C | Zone B according to EN 61131-2 | - | inputs: 4 AI PT/NI1000 16Bit | - | - | |
|
|
Kuhnke FIO AI8-Thermo 16 Bit |
694 443 06 | Temperature | 25 x 120 x 90 mm | New Product: Kuhnke FIO AI8-PT-NI-Thermo 16Bit CoE | - | CE, UL | IP 20 | Control cabinet modul | - | EtherCAT | LEDs allocated to the point of termination | Aluminium frame, plastic housing | 24 V DC (-15% ... +20%) | 0 ... +55°C | Zone B nach EN 61131-2 | - | inputs: 8 AI Thermocouple 16Bit | - | - | |
|
|
Kuhnke FIO AI4-PT-NI-Thermo 16Bit CoE |
694 443 57 | Temperature - easy configuration | 25 x 120 x 90 mm | Standard product | - | CE, UL | IP 20 | Control cabinet modul | - | EtherCAT | LEDs allocated to the point of termination | Aluminium frame, plastic housing | 24 V (-20% / +25%) | 0 ... +55°C | Zone B according to EN 61131-2 | - | inputs: 4 AI PT100/ PT1000/ TC K, J, mV 16Bit | - | - | |
|
|
Kuhnke FIO AI8-PT-NI-Thermo 16Bit CoE |
694 443 58 | Temperature - easy configuration | 25 x 120 x 90 mm | Standard product | - | CE, UL | IP 20 | Control cabinet modul | - | EtherCAT | LEDs allocated to the point of termination | Aluminium frame, plastic housing | 24 V (-15% / +20%) | 0 ... +55°C | Zone B according to EN 61131-2 | - | inputs: 8 AI PT100/ PT1000/ TC K, J, mV 16Bit | - | - |
