HMI Panel
Fully graphical operating and visualization devices
Graphical operator interfaces from Kendrion convince with maximum flexibility through a modern operating concept. The embedded visualization systems include various display sizes and resolutions and are optionally equipped with multi-touch functionality. They are less expensive than an IPC and connect your control process reliably and individually with a CODESYS HMI operator panel.
CODESYS HMI Control Panel
The visualization program runs on the Vico HMI and can connect to several different CODESYS-compatible controllers simultaneously. The simultaneous connection to the various controllers is carried out via Ethernet, if required even with its own variable mapping. The development environment for the visualization is part of the CODESYS Development System, so there are no additional costs or license fees. All modern visualisation functions of CODESYS are supported. The displaying of process data of CODESYS V2.3 and CODESYS V3 controllers is very practical, especially for extensions or modernisations. Unlike the web terminal, no processor power or programme extension is required for the visualisation.
Webterminal
The visualization is provided by the web server of the PLC. An HTML5 capable browser runs on the Vico WEB operator panel. This can connect with several different CODESYS-compatible controllers with WebVisu. The connection to the various web servers is made via the HTML protocol, so there are no additional costs or additional licenses. All modern visualization functions of CODESYS Web Visualization are supported. The display of process data from the web server is very practical, especially for extensions or modernisations with additional visualization and operating devices.
|
Title
|
Type
ascending
descending
|
Configuration
ascending
descending
|
Function
ascending
descending
|
Model
ascending
descending
|
Product status
ascending
descending
|
Display
ascending
descending
|
Resolution
ascending
descending
|
Processor
ascending
descending
|
Operating system
ascending
descending
|
Main memory
ascending
descending
|
Drive
ascending
descending
|
Interfaces
ascending
descending
|
Housing material
ascending
descending
|
Data memory
ascending
descending
|
Dimensions (W x H x D)
ascending
descending
|
IP-Protection Class
ascending
descending
|
Status indication
ascending
descending
|
Supply voltage
ascending
descending
|
Temperature range
ascending
descending
|
Details | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Vico MT 727 CODESYS HMI
|
67781000 | CODESYS HMI | Multi-Touch Panel, CODESYS V3 HMI | Panel mounted HMI | Standard product | 7" wide, IPS | 1024 x 600 (17:10) | i.MX8M mini Quad-Core CPU; 4 x 1.6 GHz | Linux | 1 GB | 4 GB eMMC memory, 2 MB NOR Flash, µSD Slot | 2 x LAN, 2 x USB, 1 x RS-232 | Aluminum frame with glass front | Flash disk 4 GB | 200 x 132 x 48 mm | IP 65 / IP 20 | - | 24 VDC (± 20 %) | 0 ... +55°C | to the product |
|
Vico MT 1027 CODESYS HMI
|
67781010 | CODESYS HMI | Multi-Touch Panel, CODESYS V3 HMI | Panel mounted HMI | Standard product | 10.1" wide, IPS | 1280 x 800 / (16:10) | i.MX8M mini Quad-Core CPU; 4 x 1.6 GHz | Linux | 1 GB | 4 GB eMMC memory, 2 MB NOR Flash, µSD Slot | 2 x LAN, 2 x USB, 1 x RS-232 | Aluminum frame with glass front | Flash disk 4 GB | 265 x 187 x 41 mm | IP 65 / IP 20 | - | 24 VDC (± 20 %) | 0 ... +55°C | to the product |
|
Vico MT 1527 CODESYS HMI
|
67781030 | CODESYS HMI | Multi-Touch Panel, CODESYS V3 HMI | Panel mounted HMI | Standard product | 15.6" wide, IPS | 1366 x 768 / (16:9) | i.MX8M mini Quad-Core CPU; 4 x 1.6 GHz | Linux | 1 GB | 4 GB eMMC memory, 2 MB NOR Flash, µSD Slot | 2 x LAN, 2 x USB, 1 x RS-232 | Aluminum frame with glass front | Flash disk 4 GB | 405 x 254 x 60 mm | IP 65 / IP 20 | - | 24 VDC (± 20 %) | 0 ... +55°C | to the product |
|
Kuhnke Vico 404
CODESYS HMI |
67780000 | CODESYS HMI | Touch Panel, CODESYS V3 HMI | Panel front Built-in unit | Standard product | 4.3" wide | 480 x 272, PSP | ARM Cortex-A8 - 1 Ghz | Linux | 512 MB | Flash | 1 x LAN, 1 x USB, 1 x RS-232/485/422 | Plastic with insert foil | Flash disk 4 GB | 107 x 147 x 34 mm | IP 66 / IP 20 | - | 24 VDC / (10 VDC … 32 VDC) | 0 ... +55°C | to the product |
|
Kuhnke Vico 704
CODESYS HMI |
67780010 | CODESYS HMI | Touch Panel, CODESYS V3 HMI | Panel front Built-in unit | Standard product | 7" wide | 800 x 480, WVGA | ARM Cortex-A8 - 1 Ghz | Linux | 512 MB | Flash | 1 x LAN, 1 x USB, 1 x RS-232/485/422 | Plastic with inlay foil | Flash disk 4 GB | 187 x 147 x 34 mm | IP 66 / IP 20 | - | 24 VDC / (10 VDC … 32 VDC) | 0 ... +55°C | to the product |
|
Kuhnke Vico 1004
CODESYS HMI |
67780020 | CODESYS HMI | Touch Panel, CODESYS V3 HMI | Panel front Built-in unit | Standard product | 10.1" wide | 1024 x 600, WSVGA | ARM Cortex-A8 - 1 Ghz | Linux | 512 MB | Flash | 1 x LAN, 1 x USB, 1 x RS-232/485/422 | Plastic with inlay foil | Flash disk 4 GB | 282 x 197 x 35 mm | IP 66 / IP 20 | - | 24 VDC / (10 VDC … 32 VDC) | 0 ... +55°C | to the product |
|
Kuhnke Vico 404 WEB
|
67780001 | Chromium web terminal | Touch Panel, web terminal | Frontpanel Einbaugerät | Standard product | 4.3" wide | 480 x 272, PSP | ARM Cortex-A8 - 1 Ghz | Linux | 512 MB | Flash | 1 x LAN, 1 x USB, 1 x RS-232/485/422 | Plastic with inlay foil | Flash disk 4 GB | 107 x 147 x 34 mm | IP 66 / IP 20 | - | 24 VDC / (10 VDC … 32 VDC) | 0 ... +55°C | to the product |
|
Kuhnke Vico 704 WEB
|
67780011 | Chromium web terminal | Touch Panel, web terminal | Panel front Built-in unit | Standard product | 7" wide | 800 x 480, WVGA | ARM Cortex-A8 - 1 Ghz | Linux | 512 MB | Flash | 1 x LAN, 1 x USB, 1 x RS-232/485/422 | Plastic with inlay foil | Flash disk 4 GB | 187 x 147 x 34 mm | IP 66 / IP 20 | - | 24 VDC / (10 VDC … 32 VDC) | 0 ... +55°C | to the product |
|
Kuhnke Vico 1004 WEB
|
67780021 | Chromium web terminal | Touch Panel, web terminal | Panel front Built-in unit | Standard product | 10.1" wide | 1024 x 600, WSVGA | ARM Cortex-A8 - 1 Ghz | Linux | 512 MB | Flash | 1 x LAN, 1 x USB, 1 x RS-232/485/422 | Plastic with inlay foil | Flash disk 4 GB | 282 x 197 x 35 mm | IP 66 / IP 20 | - | 24 VDC / (10 VDC … 32 VDC) | 0 ... +55°C | to the product |
