Kuhnke Vico 404 WEB

67780001

The Kuhnke Vico 04 series is a powerful indicator with an industrial design for the realisation of modern operating concepts. The installed software package includes the Chromium web browser and creates the possibility to visualise data from one or more arbitrary controllers with web server on a remote Kuhnke Vico 04. The visualisation takes the form of web pages based on HTML5 and Java script.

The Kuhnke Vico 04 series is based on a powerful ARM Cortex-A8 processor combined with a resistive touch display. All components are robust and long-term available.

  • widescreen display with LED backlight

  • ARM Cortex-A8 processor technology with graphics acceleration

  • Industrial construction

  • Chromium web browser

Technical details

Description Value
Configuration Chromium web terminal
Function Touch Panel, web terminal
Model Frontpanel Einbaugerät
Product status Standard product
Display 4.3" wide
Resolution 480 x 272, PSP
Processor ARM Cortex-A8 - 1 Ghz
Operating system Linux
Main memory 512 MB
Drive Flash
Interfaces 1 x LAN, 1 x USB, 1 x RS-232/485/422
Housing material Plastic with inlay foil
Data memory Flash disk 4 GB
Dimensions (W x H x D) 107 x 147 x 34 mm
IP-Protection Class IP 66 / IP 20
Status indication
Supply voltage 24 VDC / (10 VDC … 32 VDC)
Temperature range 0 ... +55°C
