Ultra Compact Door Lock

From parcel lockers to medical devices, the new Ultra Compact Lock delivers compact, energy-efficient locking technology for the next generation of battery-powered applications.

The European Lock for battery-powered locking systems

Battery-powered locking systems place high demands on every component. Installation space is limited, energy consumption directly affects battery life, and reliable operation is essential.

The Kendrion Ultra Compact Door Lock has been developed specifically for these challenges. Thanks to its innovative shape memory wire technology, it combines an exceptionally compact design with outstanding energy efficiency. Manufactured in Europe, it offers OEMs a reliable and competitive alternative for battery-powered applications such as lockers, parcel lockers, hotel doors, vending machines and medical equipment.

Discover a new generation of locking technology – engineered to maximize design freedom, extend battery life and simplify integration.

Why OEMs choose the Ultra Compact Lock

  • At least 50% less power consumption
  • Longer battery life. Fewer service visits.
  • More space for your product design
  • European engineering and manufacturing
  • Performance that competes globally

Hotel room doors

Deliver reliable, quiet and energy-efficient access for modern hotel environments. The UCL extends battery life, reduces maintenance and helps ensure a seamless guest experience.

One lock. Many applications. Designed for battery-powered locking systems.

The Ultra Compact Door Lock (UCL) is engineered to deliver reliable performance wherever space is limited and energy efficiency matters most. From smart lockers to medical devices – discover how the UCL adds value across industries and use cases.

Utra compact design

Parcel locks..

Competivie pricing

Lockers..

High security

Hotel locks..

Shock restistence

Hotel locks..

Smaller in size. Big on efficiency. Made in Europe.

Battery-powered locking systems place high demands on every component. Installation space is limited, energy consumption directly affects battery life, and reliable operation is essential.

The Kendrion Ultra Compact Door Lock has been developed specifically for these challenges. Thanks to its innovative shape memory wire technology, it combines an exceptionally compact design with outstanding energy efficiency. Manufactured in Europe, it offers OEMs a reliable and competitive alternative for battery-powered applications such as lockers, parcel lockers, hotel doors, vending machines and medical equipment.

Discover a new generation of locking technology – engineered to maximize design freedom, extend battery life and simplify integration.

Technical data

Technical data
Dimensions (LxWxD) Length 85 mm, width 55 mm and depth 18 mm
Operating voltage 12 VDC & 24 VDC
Power consumption Max. 36 W
Maximum static closing force 500 N
Ambient temperature -25 - 70° C
Lifetime 20.000 switching cycles
Shock resistance Up to 300 g in all axes
Accessories Door hook included
Mounting holes 2 holes with Ø 6,6 mm
Emergency opener Optional

Compact Lock Application Reports

Downloads

Brochures and Flyers
Digital Brochure | Locking Line: Products and Applications
PDF - 11 MB
PDF - 11 MB
Datasheets
Datasheet | Compact Lock
PDF - 539 KB
PDF - 540 KB
Brochures and Flyers
Application Report | Shock-resistant Compact Lock for lockers
PDF - 419 KB
PDF - 419 KB
Brochures and Flyers
Application Report | Secure Compact Lock for vending machines
PDF - 428 KB
PDF - 428 KB
