Permanent flat gripper HF
550 4041 10022
Flat gripper with a hard ferrite magnet in a steel pot. The housing increases the adhesive force of the permanent magnet. The maximum adhesive force is achieved when the entire surface is placed on a metallic surface. The flat gripper has a cylinder bore and can be mounted with a screw.
Technical details
| Description | Value |
|---|---|
| Design | with cylinder-bore |
| Material | hard ferrite |
| Force | 680 N |
| Diameter | 100 mm |
| Height | 22 mm |
| Diameter bore | 34 mm |
| Weight | 815 g |
| Temperature | 200 °C |
| Housing | galvanized |
