CODESYS
HMI
612 000 50
CODESYS HMI –Visualization Create modern visualizations for machines and plants directly in the CODESYS Development System and display them with CODESYS HMI (Human-Machine Interface) for operation or diagnostics on any Kuhnke Vico HMI device or PC. The visualization project can be independent of the logic application (IEC 61131-3 project). It can link to multiple different CODESYS-compatible controllers at the same time.
- Support of all visualization functions of CODESYS
- Simultaneous connection to different controllers
- Display of process data from CODESYS V2.3 and V3 controllers
- Visualization editor integrated in the CODESYS Development System
- Plant-wide access to process values
Technical details
| Description | Value |
|---|---|
| Integrated function | Extensive options for designing visualizations, for example with many available elements, visualization styles, language switching, alarm management, recipes, and trend display |
| Product status | Technology |
| Application | Visualizations for machines and plants |
| Provision | Firmware |
| Requirements | Kuhnke Vico HMI devices |
