Our Compact Collection

The compact collection is available as bridge, and half-wave rectifiers in two voltage variants. Two different housing variants allow mounting by screwing or snapping in.



Features at a glance

  • Two input voltage variants
  • High noise immunity due to overvoltage protection at input and output
  • Wide temperature range from -40°C to +80°C
  • INTORQ color code for fast recognition of the rectifier function
  • UL certified for the US market

Technical Details

Product type Function Rated input voltage U1 Output voltage Output current UL Design
BEG-142-270 Bridge Rectifier 0…270V 0.9 x U1 1A US/C Without Snap-in stud
BEG-143-270 Bridge Rectifier 0…270V 0.9 x U1 1A US/C With Snap-in stud
BEG-242-555-01 Half-Wave Rectifier 0…555V 0.45 x U1 1A US Without Snap-in stud
BEG-243-555-01 Half-Wave Rectifier 0…555V 0.45 x U1 1A US With Snap-in stud

Downloads

Datasheets
Datasheet | Compact Collection | BEG-14x-270
pdf - 464 KB
Datasheets
Datasheet | Compact Collection | BEG-24x-555-01
pdf - 457 KB
Certificates
Certificate of Compliance | UL | Half-way Rectifier
pdf - 237 KB
Certificates
Certificate of Compliance | UL | Bridge Rectifier
pdf - 286 KB
-
