Pressure Switch on Subplate (adjustable, 0.5-4 bar, max. 4 A)

60.073.40.60

The simple and compact design of this adjustable PE converter allows its use in various applications such as medical technology, dental treatment units, robotics, analysis systems, process and safety engineering. Easy mounting and high functional reliability are other advantages. By using silver contacts a long lifetime can be ensured even at high switching frequencies.

Technical details

Description Value
Product type PE-converter
Mounting Subplate
Pressure range 0.5 - 4 bar
Medium non-aggressive media
Type of electric connection Connector / flat connection
Type of pneumatic connection M5
Ambient temperature -0 ... +60 °C
Materials Housing: plastic, seal: FKM
