Kuhnke FIO
Stepper Control

694 454 56

The Kuhnke FIO Stepper Control module from Kendrion allows the control of 3 axis with up to 32 micro steps. For each motor, it offers 2 outputs for the motor phases A and B, 1 break output, 1 input for reference switches, 2 inputs for limit switches as well as the motor supply in the voltage area from 12 to 48 V DC. The configuration of the motor can comfortably be realized via a CAN over EtherCAT (CoE). Using the Stepper Control module, 3-axis gantries can be controlled with only one module. The Stepper Control module is accordingly the price optimized alternative to the function optimized FIO Drive Control module.

  • Control of 3 stepper motors incl. brakes and limit switches
  • Extendable with all Kuhnke FIO modules
  • Motion commands following DS402

Technical details

Description Value
Function motion control
Model Control cabinet modul
Digital I/Os (integrated) Outputs: 3 x 2 phase step-motor, 3 x brake, 1 x 0.5 A / Inputs: 6 x limit switches, 3 x reference
Integrated function DSP-402 Profile Position, Profile Velocity, Homing
Interfaces 3 x 2 phase stepper motor: supply voltage: 12 - 48 V DC; rated motor current: 1.8 Aeff/axis; peak current 2.5 Aeff/axis; overtemperature protection from 85°C on board
Product status Standard product
Field bus interfaces EtherCAT
Type of connection female plug with PUSH IN spring connection
Housing material Aluminium frame, plastic housing
Dimensions (W x H x D) 25 x 120 x 90 mm
IP-Protection Class IP 20
Supply voltage 24 V DC (-15% ... +20%)
Operating temperature 0 ... +50°C
Certifications CE, UL are prepared
