Locking Solenoid LHP035 (CL)
LHP0350291
The square LHP-Locking solenoid is based on the high-performance LHP solenoid from Kendrion’s High Performance Line. The LHP series is characterized by fast response times and high forces.
The locking solenoid is available in two functional variants:
LHP0350284 - Currentless unlocked: Locks when energized, unlocks via the integrated return spring when de-energized.
LHP0350291 – Currentless locked: Locked by the integrated return spring when de-energized; unlocked when power is applied.
Thanks to its locking housing, the LHP-Locking is designed for high lateral forces and is also suitable for applications with lateral loading on the locking bolt. Mounting is via a bolt pattern in the flange.
Technical details
| Description | Value |
|---|---|
| Nominal voltage | 24 V |
| Locking mode | currentless locked |
| Radial work load bearing | 3000 N |
| Duty cycle | 100 % |
| Power consumption | 14.1 W |
| Stroke | 15 mm |
| Inital force | 7.8 N |
| Return mechanism | Spring |
| Dimensions (length, width, height) | 93.5,35,35 mm |
| Emergency opener | no |
| Thermal class | F 155 |
