Overexcitation Rectifier - BEG-561-440-030-3
33005405
The Regular Collection bridge-half-wave rectifiers conduce to supply electromagnetic spring-applied DC-brakes which are released for operation with such rectifers.
The bridge-half-wave rectifiers switch over from bridge rectification to half-wave rectification after a fixed overexcitation time. Depending on the load dimensioning, switching performance may be improved or power may be reduced. Terminals 3 and 4 are located in the DC-circuit. The inductive voltage peak by DC-switching is limited by an integrated spark-suppressor on terminals 5 and 6.
Technical details
| Description | Value |
|---|---|
| Rectifier type | Overexcitation Rectifier |
| Input voltage range | 1,5 / 0,75 V |
| Max. current | 1,5 / 0,75 A |
| Quick shut down | over contact |
| Overexcitation time | 0,3 s |
| Temperature range | -40…70°C |
| Connector type | Screw Terminal |
| Certification | - |
| Output voltage | Uin x 0,89 / 0,45 V |
