Rotary Door Lock
RL 24V DC
1
2
A mechanical rotary door lock in combination with powerful bi-stable solenoid, end position sensors for the closed and the locked position of the door, as well as central connectors and an emergency opener results in a highly compact unit. High-quality plastics contribute to increased mechanical stability and long product life even with high ambient temperatures
Technical details
| Description | Value |
|---|---|
| Usage of the locking | Rotating lock / cam lock |
| Way of locking | active-locked / bistable |
| Nominal voltage | 24 V |
| Duty cycle | 2 % |
| Power consumption | 24 W |
| Max. static holding force | 400 N |
| Max. load force for electrical unlocking | 400 N |
| Connection | TE Connectivity VAL-U-LOK 1-2296207-0 |
| Snap-in function | No |
| Emergency opener | Yes |
| Operating temperature | 0 - 80 °C |
| Dimensions | 174 x 70 x 32 mm |
