CIO CANopen book size
16DI/16DO

611 300 00

The Kuhnke CIO compact I / O connects various input and output signals in a compact housing in Book size format. The process data of the PLC are made available via the CANopen interface according to the device profile CiA 401. The robust design makes it suitable for use in machine and apparatus engineering.

  • Robust housing in booksize format
  • integrated I/Os: 16DI/16DO
  • CANopen fieldbus interface

Technical details

Description Value
Configuration 16DI/16DO
Function I/O system with CANopen field bus
Model Control cabinet modul
Product status Special edition
Field bus interfaces CANopen
Interfaces CANopen
Digital I/Os (integrated) 16 DI 5ms / 16 DO 0,5A
Type of connection multi-pin plug connector
Status indication system messages, I/O status
Housing material stainless steel
Dimensions (W x H x D) 160 mm x 30 mm x 100 mm
IP-Protection Class IP 20
Supply voltage 24 V (-20% / +25%)
Operating temperature 0 ... +55 °C
