CIO CANopen
16DI/16DO/4AI-I/4AI-U/4AO-I/4AO-U/6Pt100/2Thermo
611 220 88
The Kuhnke CIO compact I / O connects various input and output signals in a compact housing for the DIN rail. The process data are made available via the CANopen interface according to the device profile CiA 401 of the higher-level control system. The robust design makes it suitable for use in machine and apparatus construction.
- Compact control cabinet module
- integrierte I/Os: 16DI/16DO/4AI-I/4AI-U/4AO-I/4AO-U/6Pt100/2Thermo
- CANopen fieldbus interface
Technical details
| Description | Value |
|---|---|
| Configuration | 16DI/16DO/4AI-I/4AI-U/4AO-I/4AO-U/6Pt100/2Thermo |
| Function | I/O system with CANopen field bus |
| Model | Control cabinet modul |
| Product status | Technology |
| Field bus interfaces | CANopen |
| Interfaces | CANopen‑Node |
| Digital I/Os (integrated) | 16 DI 5 ms, 16 DO 0,5A |
| Analogue I/Os (integrated) | 4AI-I, 4AI-U, 4AO-I, 4AO-U, 6Pt100, 2Thermo |
| Type of connection | multi-pin plug connector |
| Status indication | system messages |
| Housing material | aluminium tray with stainless steel cover |
| Dimensions (W x H x D) | 170 mm x 115 mm x 48 mm |
| IP-Protection Class | IP 20 |
| Supply voltage | 24 V (-20% / +25%) |
| Operating temperature | 0 ... +55 °C |
