Powerful industrial controller for innovative automation: Econo 328
The Econo 328 combines the performance of an industrial gateway, an automation controller and an edge computer in a compact housing. Equipped with a Raspberry Pi Compute Module 4, the device not only offers flexible memory expansion options, but also enables the connection of any removable storage media or external peripherals via USB 3.0 interfaces. With the included Linux operating system, all hardware resources are easily accessible, making the Econo 328 a powerful and versatile solution for a wide range of applications.
Thanks to its compact dimensions of just 45 x 125 x 90 mm, the Econo 328 is ideal for applications with limited space, while its performance and robustness ensure reliable automation in demanding environments. Its real-time capability is particularly suitable for industrial and robotics applications.
Econo 328 - Technical details:
- Processor: Quad-core ARM Cortex A72 (1.5 GHz), Raspberry Pi 4
- Graphics interface: HDMI interface, 3840 × 2160p @ 60 Hz (4K)
- Operating system: Linux RT
- Main memory: 2GB DDR4L
- Mass storage: µSD(HC)-Card slot up to 32 GByte, 8 GByte eMMC
- Interfaces: 2 x Ethernet (SW) 1 Gbit, 1 x Ethernet 1 Gbit, 2 x Ethernet (SW) 100 Mbit, 2x USB3.0, 1x USB2.0
- Housing material: Stainless steel, aluminum heat sink
- Mounting: DIN rail mounting
- Dimensions (W x H x D): 45 x 125 x 90 mm
- Protection class: IP20
