PLC with touchpanel
The Scout panel PLC by KENDRION combines visualisation, touch control and control electronics in one unit. Modern fieldbus interfaces and a CODESYS V3 PLC turn Scout by KENDRION into a cost-effective control system for industrial applications. The fanless PLC with touch panel Ventura Scout using PXA processor technology combines compactness with durability and performance. Modern fieldbus interfaces, CODESYS PLC and non-volatile memory enables the use of the Ventura Scout as an inexpensive industrial control for machines and plants. The edge-free and seamless polyester front foil has a high chemical resistance to cleaning agents and solvents. With its small mounting depth, Scout is particularly suitable for operating and control tasks in confined spaces.
General Technical Specifications
| Parameter | Value |
|---|---|
| Type | Scout |
| Display size / Resolution | 4.3" / 480 x 272 (PSP) |
| 7" / 800 x 480 (WVGA) | |
| 10.4" / 600 x 480 (VGA) | |
| 12.1" / 800 x 600 (SVGA) | |
| 15" / 1024 x 768 (XGA) | |
| Touch screen | 4-wire analogue resistive |
| Backlight | White LED, service life > 50000 h (at 50% max. brightness) |
| Processor | 32 Bit |
| Non-volatile memory | 8 ... 128 KB |
| Drives | Flashdisk, SD-Card Slot, SSD |
| Operating system | Windows® Embedded CE 6.0 / WEC7 |
| Software | CODESYS V3 Soft SPS, Visualisation software |
| Interfaces | RS-232, RS-485, USB 2.0, (integrated I/Os) |
| Network | Ethernet 10/100 Mbit |
| Fieldbus interface | CAN galvanically isolated, EtherCAT over Ethernet |
| Supply voltage | 24 V DC |
| Operation temperature | 0 °C ... +50 °C |
| Housing | IP 20, galvanized steel sheet casing |
| Front panel | IP 65, aluminum with seamless film cover, protection against dust, dirt and splash water |
