Inductor contour HS10017
Inductor for heating curved surfaces
The contoured heating inductor heats curved surfaces with a radius of 687 mm.
If required, several inductors can be arranged next to each other. This allows individual areas to be heated individually, resulting in particularly homogeneous surface temperatures. The high efficiency of the induction systems of approx. 98% means that the electrical energy is converted into heat very efficiently. The power density of 48 kW/m² enables rapid heating and precise temperature control up to approx. 240°C.
- High efficiency of approx. 98%
- Direct heating of the roller
- Modular design
- Cost-optimized
- Power Control 1 – 100%
- Constant temperature profile
- Maintenance-free
Technical details
| Description | Value |
|---|---|
| Dimensions (W x H x D) | 246 mm x 275 mm x 30 mm |
| Heated Section | approx. 627 cm² |
| Rated power | 3,0 kW |
| Temperature range | 0 ... 240°C |
| Power density | 48 kW/m² |
| Heating circuits | 1 |
| Inductor current | 12,5 A |
| Inductor voltage | 500 Vrms |
| Efficency | approx. 98 % |
| Duty cycle | 100 % duty cycle |
| Electrical control | For connection to Kendrion induction generators |
| Electrical connection | stranded wires |
| Product status | Standard Product |
| Standards / certification | Low Voltage Directive |
