Logic Element and Unit (also dual-pressure Valve)
47.002
Kendrion has developed a high-quality range of non-return valves for applications requiring non-return and check functions. The shuttle valve or double check valve, respectively, realizes the logical OR function in pneumatic circuits.
Technical details
| Description | Value |
|---|---|
| Pressure range | 0 - 8 bar |
| Nominal orifice | 2 mm |
| Medium | Filtered (5 µm), lubricated or non lubricated air |
| Type of pneumatic connection | M5 |
| Valve type | Check valves and flow regulators |
| Ambient temperature | -10 ... +70 °C |
| Materials | Housing: Al, seal: NBR |
