Permanent flat gripper NdFeB
550 4017 20
Flat gripper with a neodymium magnet in a steel pot. The housing increases the adhesive force of the permanent magnet. The maximum adhesive force is achieved when the entire surface is placed on a metallic surface. The flat gripper has a 8 mm threaded socket with an internal thread. It is characterized by a force of 140 N. The diameter is 20 mm, the total height of the flat gripper is 15 mm.
Technical details
| Description | Value |
|---|---|
| Design | with threaded bush |
| Material | NdFeB |
| Force | 140 N |
| Diameter | 20 mm |
| Height | 7 mm |
| Total height | 15 mm |
| Diameter threaded bush | 8 mm |
| Weight | 17 g |
| Thread | M4 |
| Temperature | 80 °C |
| Housing | galvanized |
