Half-Wave-Rectifier - BEG-261-555-01
13046441
The Regular Collection 6-pole half-wave rectifiers conduce to supply electromagnetic DC-brakes and clutches with half-wave rectified AC voltage. For DC-switching a spark suppressor is integrated via terminals 5 and 6. This significantly reduces the load on the DC-side switching contact and thereby improves its lifetime. The coil power is switched via the switching contact.
Technical details
| Description | Value |
|---|---|
| Rectifier type | Half-Wave-Rectifier |
| Input voltage range | 0 bis 555 V |
| Max. current | 0,75 A |
| Quick shut down | over contact |
| Overexcitation time | - s |
| Temperature range | -40…80°C |
| Connector type | Screw Terminal |
| Certification | UL |
| Output voltage | Uin x 0,45 V |
