Bridge Rectifier - BEG-143-270
13046390
The 4-pole Compact Collection bridge rectifiers conduce to supply electromagnetic DC-brakes and clutches with full-wave rectified AC voltage.
Technical details
| Description | Value |
|---|---|
| Rectifier type | Bridge Rectifier |
| Input voltage range | 0 bis 270 V |
| Max. current | 1,0 A |
| Quick shut down | no |
| Overexcitation time | - s |
| Temperature range | -40…80°C |
| Connector type | Screw Terminal |
| Certification | UL / CSA |
| Output voltage | Uin x 0,89 V |
