Half-Wave Rectifier - Universal Collection
32 07322B40
These half-wave and bridge rectifiers are ideal for installation in the connection boxes of medium power brake motors, brakes and solenoids. Accessories include flying leads and a variety of mounting hardware so that installation on DIN rails is also possible. Encapsulated versions offer an extended operating temperature range. In case of additional DC side fast disconnection, the induction voltage induced by inductive loads is internally limited.
Technical details
| Description | Value |
|---|---|
| Rectifier type | Half-Wave-Rectifier |
| Input voltage range | 0 bis 500 V |
| Max. current | 2 A |
| Quick shut down | yes over external contact |
| Overexcitation time | - s |
| Temperature range | -20…80°C |
| Connector type | Screw Terminal |
| Certification | - |
| Output voltage | Uin x 0,45 V |
