Accessories Fluid Technology
Electrical and pneumatic connection of valves
Kendrion standard sub plates and plug-in connectors are available for a quick electrical and pneumatic connection of each Kendrion valve series. You may use Kendrion sub plates and plug-in connectors to quickly setup a laboratory test or even as cost-efficient series solution for small series productions. The pneumatic connection typically is M5, G1/8, W1/8 or for tubing. For your individual sub plate system please contact us directly and we will find a custom-fit sub plate solution.
Kendrion's valve accessories were formerly known under the name Kuhnke.
Products
(37)
|
Title
|
Type
|
Product type
|
Accessories
|
Identification number
|
Details | |
|---|---|---|---|---|---|---|
|
One Way Trip Mechanism | 42.300 | Accessories for valves (different types) | - | 12122 | |
|
|
Mounting Flange (mech. valves type 46/74/79/81) | 43.010-1 | Accessories for valves (different types) | - | 12085 | |
|
|
Mounting Bracket (mech. valves type 46/74/79/81) | 43.010-2 | Accessories for valves (different types) | - | 12086 | |
|
|
Necessary Accessories Type 72-79-81 (pneum. actuated valves) | 43.138 | Accessories for valves type 72 | 1 x tube nipple, nozzle and tube 4 x 1 in 500m length | 12087 | |
|
|
Common Input Manifold Type 79-81-64-65 (2-fold) | 44.404.02 | Accessories for valves (different types) | - | 56033 | |
|
|
Protective Cover for Spindle of Restrictor | 47.266 | Accessories for valves type 47 | - | 12186 | |
|
|
Subplate for Valves Type 63-63.1 (tube 5x1, 3/2-way NC/NO) | 63.071.00 | Accessories for valves type 63 | - | 61953 | |
|
|
Subplate for Valves Type 63-63.1 (tube 5x1, 2/2-way NO) | 63.071.20 | Accessories for valves type 63 | - | 64104 | |
|
|
Subplate for Valves Type 63-63.1 (pre-mounted single package with supply unit) | 63.091.01 | Accessories for valves type 63 | - | 63312 | |
|
|
Subplate for Valves Type 63-63.1 (tube 5x1, 3/2-way NC/NO) | 63.091.41 | Accessories for valves type 63 | - | 65580 | |
|
|
Subplate for Valves Type 63-63.1 (tube 6x1, 2/2-way NC) | 63.091.42 | Accessories for valves type 63 | - | 198230 | |
|
|
Subplate for Valves Type 63-63.1 (tube 6x1, 3/2-way NC/NO) | 63.091.43 | Accessories for valves type 63 | - | 198231 | |
|
|
Supply Unit Type 63-63.1 (tube 5x1, DIN rail) | 63.076.00 | Accessories for valves type 63 | - | 63310 | |
|
|
Module for Intermediate Input Type 63-63.1 (tube 5x1, DIN rail) | 63.076.10 | Accessories for valves type 63 | - | 64109 | |
|
|
Supply Unit Type 63-63.1 (tube 6x1, DIN rail) | 63.077.00 | Accessories for valves type 63 | - | 82209 | |
|
|
Module for Intermediate Input Type 63-63.1 (tube 6x1, DIN rail) | 63.077.10 | Accessories for valves type 63 | - | 81855 | |
|
|
Endplate Type 63-63.1 (DIN rail) | 63.079.00 | Accessories for valves type 63 | - | 63311 | |
|
|
Mounting Unit Type 63-63.1 (DIN rail) | 63.079.10 | Accessories for valves type 63 | - | 64107 | |
|
|
Supply Unit Type 63-63.1 (tube 5x1, mounting on plain surface) | 63.086.00 | Accessories for valves type 63 | - | 61956 | |
|
|
Module for Intermediate Input Type 63-63.1 (tube 5x1, mounting on plain surface) | 63.086.10 | Accessories for valves type 63 | - | 64106 | |
|
|
Endplate Type 63-63.1 (mounting on plain surface) | 63.089.00 | Accessories for valves type 63 | - | 61955 |
