Rod gripper NdFeB
550 4025 05
Rod gripper with a neodymium magnet in a steel housing. The maximum adhesive force is achieved when the entire surface is placed on a metallic surface. The rod gripper has no thread and is usually glued or pressed in.
Technical details
| Description | Value |
|---|---|
| Design | without thread |
| Material | NdFeB |
| Force | 4.5 N |
| Height | 20 mm |
| Shortened to | 15 mm |
| Weight | 3 g |
| Temperature | 80 °C |
| Housing | steel |
