Rod gripper NdFeB
550 4022 25
Rod gripper with a neodymium magnet in a brass housing. The maximum adhesive force is achieved when the entire surface is placed on a metallic surface. The rod gripper has a central internal thread.
Technical details
| Description | Value |
|---|---|
| Design | with internal thread |
| Material | NdFeB |
| Force | 450 N |
| Height | 35 mm |
| Measure "D" | 5 mm |
| Weight | 130 g |
| Temperature | 80 °C |
| Thread | M6 x 8 |
| Fitting Tolerance | h6 |
| Housing | brass |
