Single-disc brake - optimally protected

For harsh operating conditions

Our INTORQ BFK470

Whenever the going gets tough, our BFK470 spring-applied brakes promise reliable performance. We have designed this IP66-sealed product line especially for dusty or humid operating conditions – such as wind power or crane facilities. Even extreme temperatures don't bother these brakes. They feature consistent protection and a unique modularity. You benefit from optimal versatility by using components which are freely configurable with each other. In other words, you get many variation options, all with rapid delivery times.

Features at a glance

  • 7 sizes
  • Inductive proximity sensor for functional monitoring
  • Increased maximum torques and long service life thanks to the optimized mechanical construction

Optional equipment

  • CCV (Cold Climate Version) variant: can be use down to -40°C
  • Hand-release
  • Noise-reduced rotor
  • Mounted rotary transducer
  • Functional monitoring
  • Pulse width modulation

Technical Details

Description Value
Braking torque range 2 Nm to 370 Nm
Voltage 24 V, 103 V, 180 V, 205 V
Temperature class F (155°C)
Protection Class IP66
Corrosion protection C3 optional C4/C5

Downloads

Brochures and Flyers
Brochure | INTORQ BFK470 | Spring-applied brake
PDF - 2 MB
PDF - 2 MB
Operating instructions
Operating instruction | INTORQ BFK470
PDF - 2 MB
PDF - 2 MB
PDF - 2 MB
CAD Files
3D-Models | INTORQ BFK470
ZIP - 7 MB
ZIP - 7 MB
Certificates
Certificate of Compliance | UL | INTORQ BFK470
PDF - 207 KB
PDF - 207 KB

Video - Spring-applied brake INTORQ BFK470

In this short presentation, the characteristics of the spring-applied brake INTORQ BFK470 will be highlighted and how the brake can be typically integrated will be presented. Other segments will be shown that can apply this product.
